General Specifications – 89XTC

Operating Temperature

0oC to +60oC(without heater)

32oF to +140oF

-20oC to +60oC (with heater)

-4oF to +140oF

Relative Humidity 100%

Supply Voltage 11-18Vdc, 8-16Vac

110-120V 50/60Hz

220-240V 50/60Hz

Current 1A Max

Fuse Auto Reset

1.1A Nominal

Max Inlet Air Supply 150 psi, 1035 kPa,

10.3 bar

Recommended Inlet 10 psi, 70 kPa or

Air Supply 0.7 bar above the

maximum set pressure

of the unit.

Operating Pressure

Maximum 145 psi, 1000 kPa,

10.0 bar

Minimum 5 psi, 35 kPa, 0.3 bar

Accuracy Up to 0.5% FS
